Bore Diameter: 32 mm
Stroke Length: 45 mm
Compact Cylinder Type: Standard
Piston Action: Double-Acting
Mounting Type: Through-Hole
Rod Type: Single Rod
Rod Size / Thread: M14x1.5 Female ISO
Port Type: 1/8 Female BSPT Threaded in
Cushion Type: None
Options Included: Magnetized, Switch Ready
Proof Pressure: +1.5 Mpa
Operating Pressure Range: +0.05 to +1 Mpa
Push Force at 100 psi: 563 N
Pull Force at 100 psi: 422 N
Operating Temperature Range: -10 to +60 °C
Standards Met: JIS
Overall Length: 85 mm
Overall Width: 49.5 mm
Overall Height: 45 mm
